I-SO SEA-100 economical two-way AGV is developed mainly for general 3C industries’ carrying and moving applications, an AGV device that can satisfy automated operational equipment in providing battery support and open 64 sets I/O control port. It can be applied to fixed station in transferring flexible equipment in real time . With high-strength aluminum alloy as its body part and high-torque sophisticated driving part as its design,it is navigated by magnetic stripe ,meanwhile,it has a high-accuracy localization skill and the capacity of 150 kg wight,which meets the needs of most 3C industries. It is equipped with data communication function,which helps former and latter staff or equipment to communicate and connect, multiple ports and Android system makes the humanized operating surface more convenient and easier. What’s more, it has won many national patents,its large-capacity battery and low-power consumption design enables it to work successively for 32 hours after one time charge, achieving 24X7 continuous work perfectly.
- I-SO智能AGV自动化交付托盘货物，柔性使用场地，节约场地使其周转率更高
- I-SO智能AGV简化装配工艺提高装配效率，能适应多机种同时生成工艺需求
- I-SO智能AGV连续产品入库和选择减少产地和其他工序设备人力空闲时间
- I-SO智能AGV优化转移的生产力和灵活性配置的线路控制，根据工艺需要可轻松改变路线
- I-SO智能AGV独特安全避障系统，确保人机和谐共处
- I-SO智能AGV联机联合作业，减轻了工人的劳动强度提高工作舒适度
- I-SO智能AGV精益生产设施布局或结构的无缝兼容衔接
- I-SO智能AGV使用无线通讯技术，轻松完成整体调度
- I-SO智能AGV配备故障自检，轻松实现远程技术支持和故障检修
- I-SO智能AGV智能省电模式超长待机，一次充电可连续运行48小时以上
- I-SO智能AGV投资回报率快速
| SEA-100经济型双向AGV小车系统参数： | |
引导方式 |
磁条 （RFID站点控制） |
驱动方式 |
一体式差速驱动 |
运载重量 |
（标准）150 kg / （高速） 100kg |
长x宽x高 |
1280mm×800mm×260mm (可定制) |
行驶速度 |
约35m/min<高速模式60m/min> |
最小转弯半径 |
20cm |
精度 |
±10mm |
连续作业时间 |
连续工作时间大于32小时 （标配电池） |
安全特性 |
机械防撞装置+近距光电防撞撞、障碍物传感器、紧急开关 |
