VIEW Pinnacle 250影像测量仪有着非凡的精度和生产率,优异的MTBF性能,以及在同类型自动测量系统中最低的购置成本。其独特的可编程多色环形灯(PRL)选项运用红、绿、蓝、白LED照明,可轻松应对最苛刻的应用。最新型的直性运动控制技术造就了运行速度最快、最为可靠的免维护平台,满足从无尘室到工厂车间的生产环境中,大容量、高性能的操作。
可选的软件包增强系统的通用性:
- CAD 导入(DXF/IGES) 软件
- 形状拟合和分析软件
- 离线编程软件
- QC-Calc™ Statistical Process Control (SPC) —实时分析和报告软件
- Elements™ CAD To Measure测量软件
特征:
- 测量范围:250 x 150 x 100 mm
- 25公斤承载力
- 亚微米的光栅尺分辨率
- X-Y无阻力线性马达驱动,平台速度400 mm/秒
- Z轴DC伺服回转马达驱动,100 mm/秒
- 误差映射:在XY平面非线性二维纠错
- 双重放大光学系统,固定镜头,内部放大1-4倍
- 可编程LED平台背光及同轴表面光照明
- 可编程多色环形灯(PRL)选项
- TTL激光选项,具有自动聚焦和扫描功能
- SpectraProbeTM 高分辨率彩色传感器选项
- 先进的图像处理性能,快速、精确、稳健
- 双通道,数字式,1.4兆像素的单色相机; 4:1的比例
- 次像素精度: 1/10 - 1/50 pixel
- 独立的Anthro Cart Operator工作站
- 强大的测量软件和数据分析工具可供选择
- 平均无故障工作时间 MTBF ≥ 8,000 小时
应用范围包括:
半导体/电子
BGA, μBGA, CSP, 倒装芯片, MCM, bump-on-die
引线框,引线接合,柔性线路板,连接器
SMT元件贴装
锡膏/环氧数脂胶点
芯片载体和托盒
喷墨打印机墨盒
光纤组件和MEMs
数据存储
悬置件
滑块和悬臂组(HGA)
磁盘介质基板
精密注塑和机加工件
模具和刀具
医疗设备
燃料喷射部件
手表组件
A high throughput, high accuracy dimensional metrology system
The VIEW Pinnacle 250 delivers unmatched accuracy and throughput, MTBF performance, and the lowest cost of ownership for an automated measuring system of its kind. Its exclusive multi-color Programmable Ring Light (PRL) allows use of red, green, blue, or white LED light to effortlessly image the toughest applications.
State-of-the-art linear motion control technology provides the fastest, most reliable, and maintenance-free platform available for high volume, high capacity operation in production environments ranging from clean rooms to factory floors.
Available optional software packages increase system versatility:
• CAD
• Form fitting and analysis Software
• Off-line Programming Software
• QC-Calc™ Statistical Process Control (SPC) — Real-time analysis and reporting software
• Elements™ CAD To Measure metrology software
- 250 x 150 x 100 mm (10 x 6 x 4 in.) measuring range
- 25 kg (55 lbs) maximum load
- Sub-micron scale resolution
- 400 mm c stage X, Y velocity with frictionless linear motor drives
- DC servo, rotary motor drive on Z axis, 100 mm c
- Stage Error Mapping:Non-linear 2D error corrections in X-Y plane
- Dual magnification, fixed lens optical system with 1x and 4x internal magnifications
- Programmable LED illumination system for stage backlight and coaxial surface light
- Optional Programmable Multi-Color Ring Light (PRL)
- Optional through-the-lens (TTL) laser autofocus and scanning sensor
- SpectraProbeTM high resolution chromatic sensor
- Advanced image processing for high speed, accuracy and robustness
- Dual, digital, 1.4 megapixel monochrome cameras; 4:1 ratio
- Subpixel accuracy of 1/10 to 1/50 pixel
- Standalone Anthro Cart Operator workingstation
- Choice of powerful metrology software and data analysis tools
- MTBF ≥ 8,000 hours
- Optional ESD and Class 1000 clean room compatible
Semiconductor/Electronics
BGA, μBGA, CSP, flip-chip, MCM, bump-on-die
Lead
SMT component placement
Solder paste/Epoxy glue dot
Chip carriers and trays
Inkjet printer cartridges
Fiber optic components and MEMs
Suspensions
Slider and Head Gimble Assemblies (HGA)
Disk Media substrates
Dies and tooling
Medical devices
Fuel injection components
Watch components
